Model NO.: Dereike DHB630B 1D6
Material: Aluminum
Protection: IP54
Frequency: 50 & 60Hz
OEM: Acceptable
Customized: Acceptable
Insulation Grade: F
Internal Efficiency: 85%
Trademark: Dereike
Transport Package: Packed in Cartons
Origin: China
| Technical parameters | Units | DHB 420B 1D6 |
|---|---|---|
| Maximum Flow | m3/h | 150/180 |
| Rated Vacuum | mbar | -280/-320 |
| Rated Pressure | mbar | 280/310 |
| Frequency | Hz | 50/60 |
| Voltage | V | △200-240/Y345-415 |
| Current Consumption | A | 7.5△/4.3Y |
| Power | kW | 1.6/2.05 |
| RPM | min-1 | 2800/3600 |
| Weight | Kg | 25 |
| Noise | dB (A) | 66 |
The following Pressure-flow performance curve is measured under the condition of suction of 15 °C air and exhaust pressure 1013mbar. The allowable difference is±10%. When the inlet air and ambient temperature do not exceed 25 °C, the following diagram can still be achieved.；
Dereike Side Channel Blower Applications
A. Bottling drying system
B. Fridge board drying
C. Dust-Free Plant
D. Auto part Drying
E. Plastic sheet Drying
F. Electroplating parts Drying
G. Plating Drying and Cleaning System
H. PCBA Cleaning and Drying Equipment
I. Material Handling /Material Conveying
J. Vacuum Filling Equipment
K. Tank Aeration
Etc.
Dereike Company service
A. Professional design and die-casting blowers make sure the stable capacity
B. Engineer Teams help you choosing the best suitable models
C. OEM service available
D. Full products range: ring blowers, belt-driven blowers, Atex blowers, IP55 etc
E. 1 year warrenty, 24hours service support
F. Super quality with Competitive Price
G. Delivery time is 1week after payment
H. Certificates: CCC, CE, TUV
Dereike Side Channel Blower Introduction
Dereike are a company which develop blower for 20 years. Our main products is vacuum pump, belt-drive blower, vacuum blower, regenerative blower, ring blower, side channel blower and all parts. The full range models will support you much well in the market.
Vacuum blower are using Die-casting technique, to make sure provide all blowers with stable the capacity and peformance.
The terms we appreciate is FOB, CFR, CIF and EXW etc.
Welcome contact us for more technical information and competitive price!
Dereike Intelligent M&E Equipment
Our's main products:Side channel blower,Turbo blower,High speed blower,Belt drive type blower,Anti-explosion blower,air knife,air filter,vaccum filter,muffler,pressure relief valve.etc.
